Apeks technical and recreational range in Thailand
Technical

Apeks MTX-R Regulator

<<  Back to the Regulator Page
RRP 25,690 ฿



The new MTX-R is based on the MTX, a regulator that was developed in accordance with the United States Navy Experimental Dive Unit extreme cold water test.
Innovations in design mean that the MTX-R regulator performs in almost freezing water at a depth of over 60 metres, something that very few other regulators on the consumer market can boast.
With an innovative first stage design that helps to prevent ice build up around the diaphragm, the MTX-R is reliable, rugged and expedition ready.


Image of Apeks MTX-R Second Stage Image of Apeks MTX-R Octopus Image of Apeks MTX-R First Stage Yoke Image of Apeks MTX_R first Stage DIN
Features & BenefitsSpecifications


  • A first of its kind, over-moulded first-stage end cap and environmental diaphragm to prevent ice build-up that could cause a free flow in extreme circumstances.
  • Forged 1st stage body gives maximum thermal performance.
  • Ribbed diaphragm clamp on the 1st stage ensures improved heat exchange in cold water conditions.
  • Angled HP ports allow for optimal hose routing and transmitter fitting.
  • Parallel turret ports allow for improved hose orientation.
  • Superb protection from impact damage on both the 1st and 2nd stage.
  • Simple to use 2nd stage with no dive adjustment controls and a reduced chance of free flow.
  • Double swivel hose for greater freedom of movement and comfort.
  • Patented heat exchanger surrounds the valve mechanism, dissipating the cold caused by gas expansion while drawing in the warmth of the ambient water.
  • Developed in accordance with the United States Navy Experimental Dive Unit extreme cold water test.


Connections

Yoke and DIN available

Type of first stage


Over-balanced diaphragm design, environmentally sealed

Body Type

One piece forged body

Number of HP ports

2 (7/16" UNF)

Number of MP ports

5 (3/8" UNF)

Environmental Dry Kit

Standard

First stage exterior

Satin chrome

Orientation

Convertible LH or RH

Coldwater Use

Yes - extreme

Type of second stage

Pneumatically balanced

Opening Effort Control Knob

No

Integrated Venturi Lever

No

Mouthpiece

Comfo-bite™

Exhaust tee


Diver Changeable - one set supplied

Heat Exchanger for
freezing resistance

YES

Hose type

Braided Flexi-hose

Nitrox compatible


Yes to 40% O2 when new, out of the box / Can be O2 cleaned to 100%.




DETAILS OF REGULATOR COMPONENTS :

First Stages
Second Stages
Alternate Air Sources



  SAVE MONEY ON TOP QUALITY DIVING EQUIPMENT. PURCHASE YOUR REGULATOR AND OCTOPUS TOGETHER IN ONE OF APEKS STAGE3 SETS OR HAVE A LOOK AT OUR (THAILAND ONLY)
STAGE4 SETS DISCOUNT PROMOTION WITH ORIGINAL APEKS INSTRUMENT CONSOLES
